Powered all-in-one PA system for audiences of 500-1000, 4x AX-110Lmid/ high units, 2x AX-18BA subwoofer, accessories included. This is a sweet plug-and-play solution for smaller to mid sized venues with audiences of 500 - 1000. Consisting of two mid/high units, one subwoofer, and all the requisite accessories. Surprisingly compact and easily transportable, it nonetheless delivers impressive performance. Configuration and voicing is an exercise in convenience - a simple flip of the Gain/EQ switch on the mid/high units and the Configuration switch on the subwoofer is all it takes. The system’s integrated controller presets do the rest.
| Model | AX-110L |
| Frequency Response | 62Hz-20KHz |
| Directivity Angle | H90°×V40° |
| Long-term Power(RMS) | 300W |
| Power peak handing | 600W[5Min] |
| Impedance | 8 ohms |
| Sensitivity | 103dB[2.83v/m] |
| Maximum SPL | 130dB |
| Connection | 2×NL 4 speakon |
| Enclosure Construction | 15-Birch Plywood |
| Cabinet Surface Treatment | Black Catalyzed Polyurethane Paint |
| Dimensions(H×W×D) | 300×565×370mm |
| Low | 10 IN×1[260mm] |
| High | 2 IN×1[44mm] |
| N.W. | 19.60Kg |
| Model | AX-18BA |
| Frequency Response | 40Hz-250Hz |
| Long-term Power(RMS) | 600W |
| Power peak handing | 1200W[5Min] |
| Impedance | 8 ohms |
| Sensitivity | 99dB[2.83v/m] |
| Maximum SPL | 126dB |
| Connection | 2×NL 4 speakon |
| Enclosure Construction | 15-Birch Plywood |
| Cabinet Surface Treatment | Black Catalyzed Polyurethane Paint |
| Dimensions(H×W×D) | 740×565×705mm |
| Low | 18 IN×1[460mm] |
| N.W. | 54Kg |
| Power | AC220V 50Hz-60Hz |
