The AX-212 have double 12"LF unit, double 2" compress driver. The system

adopt advanced branching map technique, made MF and LF output the same

quality SPL. The line array speaker system took over us more than 3 years

to develop and improve. The speaker box and loudspeaker also are waterproof;

it's suitable for outdoor place. lt meets the need for a high power, high bass

impact system that is versatile and scalable for a very wide range of

applications in the live sound, corporate and fixed installation fields.

Model	AX-212
Frequency Response	48Hz-20KHz
Directivity Angle	H100°×V10°
Long-term Power(RMS)	1000W
Power peak handing	2000W
Impedance	8 ohms
Sensitivity	106dB
Maximum SPL	142dB
Connection	2×NL 8 speakon
Enclosure Construction	15-Birch Plywood
Cabinet Surface Treatment	Black Catalyzed Polyurethane Paint
Dimensions(H×W×D)	365×1076×480mm
Low	12 IN×2[310mm]
High	2 IN×2[44mm]
N.W.	50Kg
