WFD-T
Features and Characteristics:
1. Utilizes full digital conference technology, in compliance with IEC 60914 international standards.
2. A multi-functional conference terminal that integrates speaking and discussion, camera tracking, and conference services.
3. Utilizes WiFi communication technology, with 2.4G and 5G frequencies available. It is within the public unlicensed frequency band defined by the International Telecommunication Union, employing full digital frequency hopping (DSSS) modulation communication technology. Through wireless audio data modulation algorithms, it enables high-speed audio transmission without compression, ensuring audio delay is less than 5.5mS.
4. In case of interference during use, the system detects it and automatically switches to an interference-free frequency.
5. Compatible with other wireless conference systems and wired conference systems, and can be used simultaneously with unified management.
6. Equipped with a 3.5-inch capacitive touch screen. It can communicate with other units or the main unit, display local time, speaking time, and can set the speaking time for timing, and display the calendar function.
7. Has the functions of key-in sign-in and supplementary sign-in reporting, with dynamic data display.
8. Supports sending notifications for tea, paper, waiters, etc., as well as short message functions.
9. The chairman unit, representative unit communicate with the wireless transmission module, using 128-bit AES Rijndael encryption algorithm to encrypt the 48-bit PIN code, automatically numbering the ID address, ensuring no duplication and preventing an awkward situation caused by ID address confusion throughout the system.
10. Exceptionally strong anti-interference capability, unaffected by mobile phone calls, Bluetooth, or WiFi signals.
11. With a built-in lithium battery capacity of 4100mA, it can operate continuously for 40 hours and enter standby mode for 160 hours. The speaking unit can automatically start when in use, automatically turning off the power when not speaking, extending the battery usage time. When charging, the chairman and representative units can operate normally.
12. Combined with the camera control system, it can automatically track the speaker and support the freeze-frame function.
13. Designed with advanced electrostatic isolation technology, avoiding the generation of static electricity even in dry environments and regions.
14. Omnidirectional microphone, ensuring the maximum attenuation of sound pickup in other directions, with an effective distance of up to 50cm for single-directional pickup.
15. The microphone pole has an indicator light ring, which can display the authorization status of the main control system.
16. Has a band-pass filter function, effectively filtering out some noise components outside the audio spectrum.
17. With the main unit, the system can expand to 4096 representative units, allowing for the setting of one executive chairman and several vice-chairmen, with the executive chairman having priority and control rights, and the vice-chairmen having priority.
18. Utilizes professional silent mechanical keys to ensure a quiet conference, allowing for peace of mind and focused attention.
19. Has an initialization function, allowing it to be restored to the factory state.
